| Description: | N9K-C93180YC-FX3 NIC Network Interface Card 48x1/10G/25G SFP+ 6x40G/100G QSFP28 | Weight: | 26.03 KGS |
|---|---|---|---|
| Model: | N9K-C93180YC-FX3 NIC Network Interface Card | Shipping: | DHL UPS Fedex Aramex EMS |
| Keywords: | N9K-C93180YC-FX3 NIC Network Interface Card | Warranty: | 3 7 3 - D A Y |
| Part Number: | N9K-C93180YC-FX3 NIC Network Interface Card | Color: | Grey |
| High Light: | ethernet interface card 48x1 hizon,ethernet interface card 10G HIZON,HIZON N9K-C93180YC-FX3 |
||
N9K-C93180YC-FX3 NIC Network Interface Card 48x1/10G/25G SFP+ 6x40G/100G QSFP28
Products Overview
Nexus 9300 with 48p 1/10G/25G SFP+ and 6p 40G/100G QSFP28, MACsec, and Unified Ports N9K-C93180YC-FX3 NIC Network Interface Card 48x1/10G/25G SFP+ 6x40G/100G QSFP28 57 dBA at 40% fan speed, 68.9 dBA at 70% fan speed, and 77.4 dBA at 100% fan speed power supply 500W AC, 930W DC, or 1200W HVAC/HVDC
Specification
|
Model Number
|
N9K-C93180YC-FX3 NIC Network Interface Card
|
|
Ports
|
48 x 1/10/25-Gbps and 6 x 40/100-Gbps QSFP28 ports
|
|
Downlink supported speeds
|
1/10/25-Gbps Ethernet 16/32-Gbps Fibre Channel
|
|
CPU
|
6 cores N9K-C93180YC-FX3 NIC Network Interface Card
|
|
System memory
|
Up to 32 GB
|
|
SSD drive
|
128 GB N9K-C93180YC-FX3 NIC Network Interface Card
|
|
System buffer
|
40 MB
|
|
Management ports
|
1 RJ-45 port L1 and L2 ports are unused
|
|
USB ports
|
1
|
|
RS-232 serial ports
|
1
|
|
Power supplies (up to 2)
|
500W AC, 930W DC, or 1200W HVAC/HVDC
|
|
Typical power (AC/DC)
|
260W
|
|
Maximum power (AC/DC)*
|
425W
|
|
Input voltage (AC)
|
100 to 240V
|
|
Input voltage
(High-Voltage AC [HVAC]) |
200 to 277V N9K-C93180YC-FX3 NIC Network Interface Card
|
|
Input voltage (DC)
|
–48 to –60V
|
|
Input voltage
(High-Voltage DC [HVDC]) |
–240 to –380V N9K-C93180YC-FX3 NIC Network Interface Card
|
|
Frequency (AC)
|
50 to 60 Hz
|
|
Fans
|
4
|
|
Airflow
|
Port-side intake and exhaust
|
|
Physical dimensions
(H x W x D) |
1.72 x 17.3 x 22.5 in.
(4.4 x 43.9 x 57.1 cm) |
|
Acoustics
|
57 dBA at 40% fan speed, 68.9 dBA at 70% fan speed, and 77.4 dBA at 100% fan speed
|
|
RoHS compliance
|
Yes
|
|
MTBF
|
238,470 hours
|
